Description
Uniformity: ≥85%
Input Voltage: 12V / 24V
Size: A1 / A2 / A3 / A4 / Customized
Thickness: 0.50″ / 0.57″ / 0.77″ / 1.34″
CCT: 5000 / 5700 / 6500
Frame Color: Black / Sliver / Golden / Customized
LED Life: 50,000 hrs
Product Details
| Product Size: | A1 / A2 / A3 / A4 / Customized | CRI: | 80 / 90 |
| LED Chip Size: | 2835 | LED PCB & Circuit: | FR4, Copper Circuit |
| LEDs/Ft: | 36 / 42 / 54 | Operating Temp: | -30°C to 45°C（-22℉ to 113 ℉ ） |
| LED Wattage/Ft(2 Edge): | 5.8 / 6.6 / 8.3 | Panel Material: | 3mm to 6mm Acrylic with Laser Dotting |
| Lux Range: | 2500-10000 Lux | Wiring Specs: | 20AWG |
| Max LED Edge Length (Inches): | 154” | Power exit: | 2.1mm/2.5mm DC Barrels, Molex, Flat Pin, Pigtail |
| Max Inches Between Edges: | 54” | Lighting Face: | Single |
Customized Yours
We welcome complexity and customized products.
Contact us with your unique requirements, no matter they are specical size, color and brightness, we will offer solutions and
