Description
LED: SAMSUNG 2835
Uniformity: ≥ 85%
Input Voltage: 12V / 24V
Size: A1 / A2 / A3 / A4 / Customized
Thickness: 0.88″
CCT: 5000 / 5700 / 6500
Frame Color: Black / Sliver / Golden / Customized
LED Life: 50,000 hrs
Product Details
| Product Size: | A1 / A2 / A3 / A4 / Customized | CRI: | 80 / 90 |
| LED Chip Size: | 2835 | LED PCB & Circuit: | FR4, Copper Circuit |
| LEDs/Ft: | 36 / 42 / 54 | Operating Temp: | -30°C to 45°C（-22℉ to 113 ℉ ） |
| LED Wattage/Ft(2 Edge): | 5.8 / 6.6 / 8.3 | Panel Material: | 3mm to 6mm Acrylic with Laser Dotting |
| Lux Range: | 2500-10000 Lux | Wiring Specs: | 20AWG |
| Max LED Edge Length (Inches): | 154” | Power exit: | 2.1mm/2.5mm DC Barrels, Molex, Flat Pin, Pigtail |
| Max Inches Between Edges: | 54” | Lighting Face: | 2.1mm/2.5mm DC Barrels, Molex, Flat Pin, Pigtail |
Single & Double Available
Customized Yours
We welcome complexity and customized products.
Contact us with your unique requirements, no matter they are specical size, color and brightness, we will offer solutions and samples!
Accessories
GLISZEN Power Supply GST Series GLISZEN DC Y Connector
