Description
LED: SAMSUNG 2835
Uniformity: ≥ 85%
Input Voltage: 12V / 24V
Size: A1 / A2 / A3 / A4 / Customized
Thickness: 0.24″
CCT: 2700 / 3000 / 4000 / 5000 / 5700 / 6500 / R / G / B
Frame Color: Sliver / White
LED Life: 50,000hrs
Product Details
| Product Size: | A1 / A2 / A3 / A4 / Customized | CRI: | 80 / 90 |
| LED Chip Size: | 2835 | LED PCB & Circuit: | FR4, Copper Circuit |
| LEDs/Ft: | 36 / 42 / 54 | Operating Temp: | -30°C to 45°C（-22℉ to 113 ℉ ） |
| LED Wattage/Ft(2 Edge): | 5.8 / 6.6 / 8.3 | Panel Material: | 4mm to 6mm Screened Acrylic,Laser Dotting |
| Lux Range: | 600-10,000 Lux | Wiring Specs: | 22/24AWG |
| Max LED Edge Length (Inches): | 72” | Power exit: | 2.1mm/2.5mm DC Barrels, Molex, Flat Pin, Pigtail |
| Max Inches Between Edges: | 24” | Lighting Face: | Double |
Customized Yours
We welcome complexity and customized products.
Contact us with your unique requirements, no matter they are specical size, color and brightness, we will offer solutions and samples!
Accessories
Snap Frame Series GLISZEN Power Supply GST Series GLISZEN DC Y Connector
Application Layout
LED Panel Meanwell Power Supply AC Power-in Plug
